African Blackwood

> Hardwoods > Fabaceae > Dalbergia > melanoxylon

African blackwood (Dalbergia melanoxylon)

Common Name(s): African blackwood, mpingo (Swahili), grenadilla

Scientific Name: Dalbergia melanoxylon

Distribution: Dry savanna regions of central and southern Africa

Tree Size: 20-30 ft (6-9 m) tall,

                 2-3 ft (.6-1.0 m) trunk diameter

Average Dried Weight: 79 lbs/ft3 (1,270 kg/m3)

Specific Gravity (Basic, 12% MC): 1.08, 1.27

Janka Hardness: 3,670 lbf (16,320 N)

Modulus of Rupture: 30,970 lbf/in2(213.6 MPa)

Elastic Modulus: 2,603,000 lbf/in2(17.95 GPa)

Crushing Strength: 10,570 lbf/in2(72.9 MPa)

Shrinkage: Radial: 2.9%, Tangential: 4.8%,

                  Volumetric: 7.7%, T/R Ratio: 1.7

Color/Appearance: Often completely black, with little or no discernible grain. Occasionally slightly lighter, with a dark brown or purplish hue. The pale yellow sapwood is usually very thin, and is clearly demarcated from the darker heartwood.

Grain/Texture: Grain is typically straight; fine, even

texture and good natural luster.

Rot Resistance: Heartwood is rated as very durable in regards to decay resistance, though only moderately resistant to insects/borers. The lighter colored sapwood is commonly attacked by powder-post beetles and other borers.

Workability: Very difficult to work with hand or machine tools, with an extreme blunting effect on cutters. African blackwood is most often used in turned objects, where it is considered to be among the very finest of all turning woods—capable of holding threads and other intricate details well. When made into clarinet or oboe bodies, the wood is typically processed on metal-working equipment, giving it a reputation as being metal-like in some of its working properties.

Odor: African blackwood has a mild—though distinctive—scent while being worked.

Allergies/Toxicity: Although severe reactions are quite uncommon, African blackwood has been reported as a sensitizer. Usually most common reactions simply include eye, skin, and respiratory irritation. See the articles Wood Allergies and Toxicity and Wood Dust Safety for more information.

Pricing/Availability: African blackwood is very expensive, on par with true ebonies such as Gaboon Ebony in the Diospyros genus. Since the tree grows so slowly, and is generally small and gnarly, available boards tend to be narrow—though large clear sections have occasionally been harvested from older trees that yield bookmatched guitar backs (~8″ wide).

Sustainability: African blackwood is listed on CITES appendix II under the genus-wide restriction on all Dalbergia species—which also includes finished products made of the wood. It’s also reported by the IUCN as being near threatened. Technically it doesn’t meet the Red List criteria of a vulnerable or endangered species, but is close to qualifying and/or may qualify in the near future.

Common Uses: Musical instruments (guitars, clarinets, oboes, etc.), inlay, carving, tool handles, and other turned objects.

Comments: To be considered the original ebony, African Blackwood was imported and used in Ancient Egypt thousands of years ago. Even the name “ebony” has an Egyptian derivation as “hbny”—which has been shown to refer to primarily to Dalbergia melanoxylon, rather than the species which are considered to be ebony today: such as those in the Diospyros genus. In addition, African blackwood is technically in the Rosewood genus (Dalbergia), and is more stable and resistant to movement and warping than other types of ebony.

African blackwood is considered to be among the hardest and densest of woods in the world; indeed, among some 285 species tested, (including Lignum Vitae), Gabriel Janka originally found African Blackwood to be the very hardest. Unfortunately, many online sources list African blackwood’s Janka hardness at only ~1700lbf—which seems very unlikely given its confirmed specific gravity.

Images: Drag the slider up/down to toggle between raw and finished wood. A special thanks to Steve Earis for providing the endgrain wood sample and turned photo of this wood species.

[caption id="attachment_21396" align="alignnone" width="225"] African blackwood (Dalbergia melanoxylon)[/caption]



Watch video of wood finish being applied.

African Blackwood (turned)
African Blackwood (turned)

Identification: See the article on Hardwood Anatomy for definitions of endgrain features.

African blackwood (endgrain 10x)
African Blackwood (endgrain)
African blackwood (endgrain 1x)

Porosity: diffuse porous

Arrangement: solitary and radial multiples

Vessels: medium to large, few; dark gray to black deposits present

Parenchyma: diffuse-in-aggregates, vasicentric, winged, and banded (sometimes marginal and/or reticulate)

Rays: narrow, normal spacing

Lookalikes/Substitutes: Commonly confused with species of ebony (Diospyros spp.)—both of which can have completely black heartwood.

Notes: Portions of the lighter sapwood have been included to help illustrate anatomical features more clearly. In very dark woods, it’s very useful to look at sapwood rather than heartwood to help see details that would otherwise be obscured in blackness.

> Hardwoods > Fabaceae > Dalbergia > Related species

Camatillo
(Dalbergia congestiflora)
Guatemalan rosewood
(Dalbergia cubilquitzensis)
Laotian rosewood
(Dalbergia lanceolaria)
Huanghuali
(Dalbergia odorifera)
Palo escrito
(Dalbergia paloescrito)

Related Content:

Subscribe
Notify of
guest
36 Comments
Inline Feedbacks
View all comments
Hiep

There is another tree also named African blackwood, Erythrophleum africanum. In fact, I found no plant of Erythrophleum genus on your site. Some members of this genus are considered ironwood due to their extreme densitity and blunder effect on saws

Cindy Potgieter

Good day. Please can you tell me the wood type, very, heavy.

Loren Javernick

African Blackwood is an absolute dreamboat on the lathe. You’ll need a sharp chisel but despite its rather immense hardness it cuts like butter, so smooth, and it can hold the finest detail. It’s my favorite wood to turn. I’ve never had a reaction to the dust either though I mostly don’t breathe it anyways. But some woods give me sinus issues, I haven’t noticed that with Blackwood for what it’s worth. It’s the cocoa butter on my French toast.

sven

A turned bowl from african blackwood

Victoria Howard

Hello. I was given this African carved lion quite a few years ago by a women who bought it in Africa and had it shipped to the United States. We know very little about this beautiful carving. It would be helpful if someone knows what kind of wood it’s made from. After some research I feel like Ebony wood is the closest. Its VERY heavy.

Last edited 2 years ago by Victoria Howard
Rohan Geldenhuys

Hi Victoria….Do you mind posting a photo please? Simplest explanation or way…. Sand or scrape somewhere (bottom) of the carved piece…. Expose the “fresh” wood! If you see clear wood grain/ lines…..then its African Blackwood. Ebony is just an odd pitch black “void” looking wood!!! Another way: Africa is Quite big! If bought in West Africa, then 99% of the time it will be Ebony. If bought in Southern Africa, then it should be African Blackwood, and i presume she did.. Be advised, they do however polish these carvings with black shoe polish……might just end up with iron wood or… Read more »

Alfy

Hi, can you tell me what wood this is? This item is made of wood indigenous to Africa, in the early 1900s and is very heavy- heavier than ipe.

Screen Shot 2020-07-27 at 8.48.41 PM.jpg
Wilson

It’s that wood is good for build a batiment (a house by exemple) ?

Alex Smith

yes it can be but buying all that wood would be highly expensive and how would you even find it during the nighttime?

Timothy Tikker

in 1992 PBS Nature broadcast a documentary about African Blackwood, “Mpingo: The Three of Music.” I just found it online: https://www.youtube.com/watch?v=wUcW1dRH2XQ The demand for this wood for clarinets, oboes, bagpipes etc really has reached a crisis point. The largest woodwind manufacturing companies keep up with the huge demand for this wood (in the music world we usually call it grenadilla) by using it before it’s fully seasoned, pressure-treating it with oil to compensate. Unfortunately, the result is a wood that isn’t stable in the long term, so that instruments “play out” after a number of years, going so irremediably out… Read more »

ExRxIT

I just finished 3 guitars with African blackwood bridges. To my dismay the bridge on the first one had pulled up off the soundboard before I finished the third one. The other bridges are pulling away too. I never had this problem with ebony. I just wiped the bottom of the first bridge with acetone and was surprised at how much black oil came out of the wood. When no more black stuff came off on the rag I re-glued the bridge. Hoping it will stay put now. The other 2 will have to be done over too. I’ve seen… Read more »

ExRxIT

The bridge blanks came from a reputable dealer of luthier woods and were stored in my shop for several months. I’m pretty sure moisture and wood movement weren’t the issue. After acetone and re-gluing, all 3 bridges have stayed down. This stuff is just really waxy or oily. Clogs sandpaper like crazy. That may be why it takes such a nice polish with no finish.

Eric Schwarzenbach

African blackwood is also sometimes known as grenadilla.

Tony

Did anyone try to test its impact strength? comparing to Kingwood for example? Any data available for it is appreciated.

Alex

Does anyone know if this wood’s brown colour is soluble in water?

Robert Howe

Yes, the colour is soluble. I have an English horn bell which discolored when soaked overnight. The instrument’s maker claims the wood was not stained.

Ed Davidson

African Blackwood is a great contrasting color embellishment on small turnings like yo-yos and tops. It’s super fine grain is perfect for ornamental turning as well.

Rick

I am wondering if African Blackwood would work well for an axe handle considering that it has a fairly low elastic modulus which I am assuming allows the axe to bend more and absorb shock. Typical axe woods like hickory are not too far off from it in terms of elastic modulus. I am curious about this because African Blackwood is much more dense and rot resistant than hickory as well as having a much higher modulus of rupture. All of this seemingly in my mind would make it a superior wood for an axe handle even though this tree… Read more »

Alex

The trees do not grow large or fast enough for this to be a good or sustainable use for this wood.

Fyl

If it’s of the “viking family heirloom for murder mayhem” kind….maybe?

If it’s a crude tool for chopping crap down or splitting logs for the fireplace, NO. It’s rare, expensive, and restricted so it’ll only get rarer and more expensive still.

Loren Javernick

You could probably do it but not a whole axe handle. Just the part where your hand grips? I’d say yeah. If u found a piece large enough to make an entire axe handle be ready to spend like $300 on it at least :D

McSwervy

I’m thinking about making a small pipe using African Blackwood, can anyone here speak to it’s heat resistant properties?

AngryReader

It is a good wood for pipes. I use a small blackwood pipe and I know of people who use african blackwood for bowl inserts.

OYO BeN

I have a source of supply need international buyers and prices per cubic meter log

Tai Fu

I bought some ebony from a lumberyard, but discovered that the wood exuded some fragrance when sawn. So I started digging and I really think I have african blackwood rather than ebony as the seller claimed. The piece on the right seems to smell like ebony, but I do not know if smell is a reliable identification. I rubbed some shellac onto the wood with my bare finger to see what the wood looks like, and the wood exuded a LOT of oil. I tried the same thing on known samples of gaboon ebony and macassar ebony (both of them… Read more »

Tai Fu

I never had any issue with gluing ebony except for one time when the glue I used was mixed improperly (was using hot hide glue), and the ebony probably oxidized for quite some time. Since I am making bridges I don’t really want to use epoxy because it might need to be removed later on for whatever reason.

Loren Javernick

I had success gluing it to maple once by turning the Blackwood first into a piece with 1/4” dowels coming off both sides, then drilled a 1/4” hole into the maple, glued them together, and turned the whole thing into a pretty cool spoon, maple with a Blackwood stripe in the handle.

Last edited 1 year ago by Loren Javernick
jacobwalker

why is the African backwood endangerd

Joel

How much weight can a 2ft. x 8ft. log of African Blackwood support before breaking.

Alex

Depends where the weight is focused and if there is any supporting structures.

Carl Landis

I’ve used this wood as well as Kamagong for impact type weapons
the gravity question is not as important as is the question of
durability. These hardwoods are normally used for strength training
in the wrist, forearms and shoulders and should not be used two
man drills.

I’ve seen rattan sticks break Kamagong in half, because of the
brittleness of these type of hardwoods the best solution I’ve
found is Cold Steel’s polypropylene sticks. They have the weight
and density of African Black wood and is almost indestructible
and more cost effective than wood.

Jgorish

Stickman Escrima Products were the first plastic sticks to be successfully marketed. The “Panther” sticks have similar weight and density to woods like ebony, are much more durable than hardwoods and feel more “wood-like” than polypropylene. The “Panther II” are lighter but also can be finished to look like wood, and are also much more durable.

Scott Denison

I have a question about the Janka test with African Blackwood. If the steel ball is pushed into the wood at the depth that all of test criteria specify, which is 2900lbs, what does the specific gravity have to do with the actual Janka test and what does it mean? I’m planning on have an impact weapon made with this wood and I’m interested in durabilily of this specific wood.
